UL-Recognized Anti-Vandal Switches with up to 16A and TV-6 Rating

  • PS-5 ANTI VANDAL SWITCHES
  • BNE
  • Plastic Bag
  • CE, ROHS, SGS
  • China
  • 85365000
  • UL-Recognized Anti-Vandal Switches with up to 16A and TV-6 RatingPS5 Anti-vandal Switch up to 16A and TV-6 Rating
  • UL/ENEC-recognized
  • Metal Knob detachable from main switch, patented easy snap-in assembly
  • Standard 19mm round hole mounting with nuts for fastening
  • ON-OFF, or Momentary ON, DPST, SPST
  • Ring & power symbol illuminated icon available

  • 16A 125/250VAC (UL,CUL)
  • 16(4)A 250V~ T125/55 (ENEC)
  • 16(8)A 250V~ T125/55 (ENEC) optional
  • TV-6 125V~ T55, 25E3 (cURus) optional
  • 8[128]A 250V~T55 1E4 (cURus, ENEC15) optional
  • Initial contact resistance: 20m max.
  • Insulation resistance: 100M min. at 500VDC
  • Dielectric strength: 1,000 VAC for 1 minute
  • Metal Knob detachable from main switch, easy snap-in assembly
  • Standard 19mm round hole mounting with nuts for fastening
  • Other bigger sizes available upon request for customization
  • ON-OFF, or Momentary ON, DPST, SPST
  • Ring & power symbol illuminated icon
  • VDC LED illumination regardless of anode and cathode polarity
  • On-Off & momentary function
  • Quick-connect, solder and pcb terminals
  • M19 bushing, screw mounting
  • Actuator & bushing material: SUS
  • Top len: PC
  • Connected frame: PA66+GF
