Prod Size: 6x6mm, 12x12mm
Rating: 50mA 12VDC
Contact Resistance: 100mmax.
Insulation Resistance: 100Mmin.
Operation Force: 100g, 160g, 260g
Communication equipments, Audio and video products
Rating: 50mA, 12VDC
Travel: 0.3± 0.15mm
1) Scope: This specification covers the requirements for single key switches which have no keytop(TACT SWITCHES:MECHANICAL CONTACT).
2) Operating Temperature Range: -15 to 60°C (normal humidity, normal press.)
3) Storage Temperature Range: -25 to 70°C (normal humidity, normal press.)
4) Test Conditions
Tests and measurements shall be made in the following standard conditions unless otherwise specified:
Normal temperature (temperature 16°C)
Normal humidity (relative humidity 63 to 74%)
Normal pressure (pressure 102KPa)
APPEARANCE, STYLE, AND DIMENSIONS
1) Appearance: Functionally free from rust,crack and bad plating
2) Style and Dimensions: Reference per attached outline drawing
3) Type of actuation: Tactile feedback
4)Contact Arrangement: SPST
5) Maximum Ratings: DC 12V 50mA
TACTING SWITCH SPECIFICATION
