Tact Switch with LED (TS4-1-G)

  • TS4-2-U

  • Silver

  • ISO, RoHS, CE

  • SGS Approval

  • BNE

  • Bag

  • TS4-1-G

  • China

  • 85365000

Tact Switch with LED (TS4-1-G)Specifications

Circuit: Push (on)
Current rating: 30mA
Voltage rating: 30VDC
Dielectric resistance voltage: 500VAC for 1 minute
Operation foce: 200+/50gf
Total travel: 0.7mm+-0.2mm
Operation life: 100000 cycles min
Solder specification: 260 degree for 5 second
Function: OFF-(ON)

Material:
Frame: Nylon 66, UL rated: 94V-2Min
CAP: ABS
Termial: Brass, Gold or Tin plated


Product Description
* Pure silver contacts, with 3.0µm silver plated in terminals. Using UL T155 thermo-plastic PBT
*Widely used in home appliance, electronic equipment, automatic machine, communication equipment, car electron, apparatus and instrument, electric motion tool, etc
* Good substitution for Omron, Honeywell, Burgess, Marquard


Product Description
* Pure silver contacts, with 3.0µm silver plated in terminals. Using UL T155 thermo-plastic PBT
*Widely used in home appliance, electronic equipment, automatic machine, communication equipment, car electron, apparatus and instrument, electric motion tool, etc
* Good substitution for Omron, Honeywell, Burgess, Marquard
