SGS Spst Miniature Snap Action Micro Switch

  • NSM4-500D

  • Single Type

  • Military Products

  • saipwell

  • ISO9001, UL, CE, CCC

  • Microwave Use

  • BNE

  • Bag

  • CE, ROHS, SGS

  • China

  • 85365000

SGS Spst Miniature Snap Action Micro SwitchTypical Specifications

1. Rating: 5A 125/250 VAC
2. Operating Force: 30¡ 15gf
3. Release Force: 15¡ 10gf
4. Free Position: 11.0¡ 0.8mm
5. Operating Position: 9.0¡ 0.8mm
6. Release Position: 9.2¡ 0.8mm
7. Movement Differential: 0.35¡ 0.2mm
8. Total Travel Position: 7.0¡ 0.3mm
9. Operating life: 50, 000 cycles


Product Description
1) Widely used in home appliance, electronic equipment, automatic machine, communication equipment, car electron, apparatus and instrument, electric motion tool, etc
2) Pure silver contacts, with 3.0µm silver plated in terminals. Using UL T155 thermo-plastic PBT
3) Good substitution for Omron, Honeywell, Burgess, Marquard


Product picture and Dimension



Packaging & Shipping
1) Packaging: Carton
2) Shipping
Fedex, DHL, UPS, TNT for samples, 3-7 days.
By Air or by Sea for batch goods, 10-30 days.
3) Payment Terms
T/T, L/C, PayPal; 30% deposits; 70% balance before delivery

Why choose us?
1) We can provide you with different types of micro switches for your selection.
2) MOQ: 2500pcs,mixed order acceptable, welcome trial order.
3) We can provide free samples for your test.
4) Various operating force,height and colour for one switch for your choice.
5) Safety, on-time delivery, excellent quality with competitive price.
6) OEM and ODM professional design.
