SGS Miniature Micro Pushbutton Switch

  • MPS11
  • Multi Control Switch
  • Power Built-in Type
  • Control Button, Start Button, Reset Button, Disconnector
  • Single-pole on-off Switch
  • Type c Contact
  • Retro-reflective Mode
  • ISO9001, UL, CE, CCC
  • BNE
  • Bag
  • Single pole push power switch up to 16A 125VAC for
  • China
  • 85365000
SGS Miniature Micro Pushbutton Switch16A 125VAC (UL, CSA)


10A 250VAC (UL, CSA)

TV-5 (UL, CSA)

5A/80A 250VAC ~μT85 (VDE, SEMKO, NEMKO, DEMKO, FIMKO)

Initial contact resistance: 20m ohm max.

Insulation resistance: 100M ohm min, at 500VDC

Dielectric strength: 1, 000 VAC for 1 minute

Electrical life: 10, 000 cycles

Temperature range: -20 to +85 degrees in Celsius

Base: Phenolic, UL rated 94V-0
Frame cover: Chrome rainbow zinc or nickel plated steel

Actuator: Nylon 66, UL rated 94V-2, min

Spring: Piano wire

Contacts: Silver copper alloy

Terminal: Silver plated copper

Latch pin: Piano wire

Terminal Seal: Epoxy

Product Description

1) Good replacement for Omron, Honeywell, Burgess, Marquard

2) Widely used in home appliance, electronic equipment, automatic machine, communication equipment, car electron, apparatus and instrument, electric motion tool, etc.
Our cooperative partner


FAQ
Q1--What is your MOQ?
In general ,Our MOQ is 2500 pcs, it will be more convenient and safety on packaging. Of course, it can be negotiable according to your situation.
Q2--What is the delivery time ?
3-7 days for samples; 10-30 days for batch goods.
Q3--Can you give me samples to test and how many samples?
Yes, we provide free samples, with shipping and taxes paid by the buyer. Usually, free samples are 5 pieces.
Q4--Does your products through UL, ROHS certification and so on?
Yes, our switches are with UL, CUL, VDE, TUV, ENEC, CE, EK, CQC, Nimko, Fimko, Simko, Dimko, CB approved, meet EU, RoHS standard.
Q5--Can you accept OEM?
Yes, we can accept OEM and ODM, they are welcome by us. But please offer us your authorization certification.
Q6--Is there cheap shipping cost to our country?
For small order, express will be best. And for bulk order, shipping by sea is better, but it takes much time.
Contact Rating Dependent upon contact material
Mechanical life 50000 make-and -break cycles at full load
Contact resistance 20m Ω max.initial @2-4 VDC 100mA, for both silver and gold palted contacts
Insulation Resistance 1000M Ω min.@seal level
Operating tenmperature -30 ºC to +85 ºC
Cap installation force 10 lbs,max ,permissible




*****Material*****
Case & Bushing Glass filled nylon6/6 or nylon 4/6(UL94v-0)
Plunger Glass filled nylon or glass filled polyester(UL 94V-0)
Switch Support Copper alloy or steel, tin palted
Switch Support Retauber Stainles steel
N.O&N.C Contacts Brass, with gold plate over nikel plate
Common contacts & all terminals copper alloy with gold plate over nickel plate
Terminal seal Epoxy
