Rating: 3A 125VAC, 1A 250VAC, 0.3A 50VDC
Contact resistance: 20m ohm
Insulation resistance: DC500V 100M ohm (min. )
Dielectric voltage-withstand: 1, 000 VAC for 1 minute
Operation force: 250± 100 gram
Life cycle: 10, 000 cycles
Temperature range: 0 to + 65 degrees in Celsius
Base: Nylon 94V-2
Knob: Nylon 94V-2, red, gray or optional color
Spring: Piano wire
Contact: Silver plated brass or copper
Gold plating optional
1) Widely used in home appliance, electronic equipment, automatic machine, communication equipment, car electron, apparatus and instrument, electric motion tool, etc.
2) Good replacement for Omron, Honeywell, Burgess, Marquard.
Packaging & Shipping
1) Packaging: Carton
Fedex, DHL, UPS, TNT for samples, 3-7 days.
By Air or by Sea for batch goods, 10-30 days.
3) Payment Terms
T/T, L/C, PayPal; 30% deposits; 70% balance before delivery
Why choose us?
1) We can provide you with different types of micro switches for your selection.
2) MOQ: 2500pcs,mixed order acceptable, welcome trial order.
3) We can provide free samples for your test.
4) Various operating force,height and colour for one switch for your choice.
5) Safety, on-time delivery, excellent quality with competitive price.
6) OEM and ODM professional design.
Our cooperative partner
Q1--What is your MOQ?
In general ,Our MOQ is 2500 pcs, it will be more convenient and safety on packaging. Of course, it can be negotiable according to your situation.
Q2--What is the delivery time ?
3-7 days for samples; 10-30 days for batch goods.
Q3--Can you give me samples to test and how many samples?
Yes, we provide free samples, with shipping and taxes paid by the buyer. Usually, free samples are 5 pieces.
Q4--Does your products through UL, ROHS certification and so on?
Yes, our switches are with UL, CUL, VDE, TUV, ENEC, CE, EK, CQC, Nimko, Fimko, Simko, Dimko, CB approved, meet EU, RoHS standard.
Q5--Can you accept OEM?
Yes, we can accept OEM and ODM, they are welcome by us. But please offer us your authorization certification.
Q6--Is there cheap shipping cost to our country?
For small order, express will be best. And for bulk order, shipping by sea is better, but it takes much time.
|Contact Rating ||Dependent upon contact material |
|Mechanical Life ||40,000 make-and-break cycles |
|Contact Resistant ||10mΩ max. Initial @ 2-4VDC 100mA for both silver and gold plated contacts |
|Dielectric Strength ||1,000V RMS@sea level |
|Insulation Resistance ||1,000MΩ min. |
|Temperature Range ||-10 to +85 degree |
| Case ||Diallyl phthalate (DAP) (UL94V-0) |
|Actuator ||Nylon, Black std |
|Bushing ||Brass, nickel plated |
|Housing ||Stainless Steel |
|Switch Support ||Brass, tin plated |
|Terminal/Contact ||Brass, with silver or gold plated |
