NTE2005
Single Type
Military Products
PIONEER
ISO9001, UL, CE, CCC
BNE
Bag
CE, ROHS, SGS
China
85365000
Item | Value | |
Rating | 3 (0.5)A 250V AC, 1(0.5)A, 0.5(0.2)A, 0.3(0.1)A, 0.1(0.05)A | |
Safety approvals | UL, CUL, VDE, TUV, ENEC, CE, EK, CQC | |
Endurance | Mechanical(60times/min): ≥1,000,000 cycles Electrical(25times/min): ≥10,000 cycles | |
Temperature Degree | T85, T105, T125,T150, T200 | |
Protection Degree | IP40 | |
Contact resistance | ≤30mΩ (initial value) | |
Insulation Resistance | ≥100MΩ (500V DC) | |
Dielectric strength | Terminal to terminal | AC1000V,50/60Hz,1min |
Terminal to ground | AC3750V,50/60Hz,1min | |
Vibration resistance | 10-55Hz,1.5mm Double amplitude | |
Operating Speed | 0.1mm-1m/s (related with actuator forms) | |
Shork Resistance | Destruction: OF >0.5N:1000m/S2, OF ≤0.5:400m/S2 Malfunction: OF >0.5N:200m/S2,OF ≤0.5N:100m/S2 | |
meet EU, RoHS standard | ||
Weight | Approx. 1.6g(No lever) |
Item | Value | |
Rating | 3 (0.5)A 250V AC, 1(0.5)A, 0.5(0.2)A, 0.3(0.1)A, 0.1(0.05)A | |
Safety approvals | UL, CUL, VDE, TUV, ENEC, CE, EK, CQC | |
Endurance | Mechanical(60times/min): ≥1,000,000 cycles Electrical(25times/min): ≥10,000 cycles | |
Temperature Degree | T85, T105, T125,T150, T200 | |
Protection Degree | IP40 | |
Contact resistance | ≤30mΩ (initial value) | |
Insulation Resistance | ≥100MΩ (500V DC) | |
Dielectric strength | Terminal to terminal | AC1000V,50/60Hz,1min |
Terminal to ground | AC3750V,50/60Hz,1min | |
Vibration resistance | 10-55Hz,1.5mm Double amplitude | |
Operating Speed | 0.1mm-1m/s (related with actuator forms) | |
Shork Resistance | Destruction: OF >0.5N:1000m/S2, OF ≤0.5:400m/S2 Malfunction: OF >0.5N:200m/S2,OF ≤0.5N:100m/S2 | |
meet EU, RoHS standard | ||
Weight | Approx. 1.6g(No lever) |
