IP67-Rated and UL-Recognized Anti-Vandal Switches with up to 16A and TV-6 Rating

  • PS5-210MH-BUD-0RAC
  • Multi Control Switch
  • Power Built-in Type
  • Control Button, Start Button, Check Button
  • Single-pole on-off Switch
  • Type b Contact
  • Retro-reflective Mode
  • PIONEER
  • ISO9001, UL, CE, CCC
  • Illuminated or Non-Illuminated
  • BNE
  • Polly Bag
  • ROHS, SGS
  • China
  • 85365000
IP67-Rated and UL-Recognized Anti-Vandal Switches with up to 16A and TV-6 RatingPushbutton switch
IP67-Rated and UL-Recognized Anti-Vandal Switches with up to 16A and TV-6 Rating

Using the industry: Boat ship communications equipment, outdoor lighting remote call utility communication equipment medical equipment Rating: 2A 250V 5A 125V Waterproof Level: IP67 Install Size: D

16A 125/250VAC (UL,CUL)
16(4)A 250V~ T125/55 (ENEC)
16(8)A 250V~ T125/55 (ENEC) optional
TV-6 125V~ T55, 25E3 (cURus) optional
8[128]A 250V~T55 1E4 (cURus, ENEC15) optional
Initial contact resistance: 20m max.
Insulation resistance: 100M min. at 500VDC
Dielectric strength: 1,000 VAC for 1 minute
Metal Knob detachable from main switch, easy snap-in assembly
Standard 19mm round hole mounting with nuts for fastening
Other bigger sizes available upon request for customization

ON-OFF, or Momentary ON, DPST, SPST
IP65 ~ IP67 protection level
Ring & power symbol illuminated icon
VDC LED illumination regardless of anode and cathode polarity
On-Off & momentary function
Quick-connect, solder and pcb terminals
M19 bushing, screw mounting
Actuator & bushing material: SUS
Top len: PC
Connected frame: PA66+GF



Packaging & Shipping
1) Packaging: Carton
2) Shipping
Fedex, DHL, UPS, TNT for samples, 3-7 days.
By Air or by Sea for batch goods, 10-30 days.
3) Payment Terms
T/T, L/C, PayPal; 30% deposits; 70% balance before delivery

Why choose us?
1) We can provide you with different types of micro switches for your selection.
2) MOQ: 2500pcs,mixed order acceptable, welcome trial order.
3) We can provide free samples for your test.
4) Various operating force,height and colour for one switch for your choice.
5) Safety, on-time delivery, excellent quality with competitive price.
6) OEM and ODM professional design.
7) Our cooperative partner

Our clients include famous domestic public corporations, such as Joyoung, H&T, Topband, Newcapec, Routon, Haier, Siasun, Treyo. Also we cooperate with many famous overseas brand, such as Whirlpool, Siemens, Electrolux, Panasonic, Eaton, Emerson etc.

FAQ
Q1--What is your MOQ?
In general ,Our MOQ is 2500 pcs, it will be more convenient and safety on packaging. Of course, it can be negotiable according to your situation.
Q2--What is the delivery time ?
3-7 days for samples; 10-30 days for batch goods.
Q3--Can you give me samples to test and how many samples?
Yes, we provide free samples, with shipping and taxes paid by the buyer. Usually, free samples are 5 pieces.
Q4--Does your products through UL, ROHS certification and so on?
Yes, our switches are with UL, CUL, VDE, TUV, ENEC, CE, EK, CQC, Nimko, Fimko, Simko, Dimko, CB approved, meet EU, RoHS standard.
Q5--Can you accept OEM?
Yes, we can accept OEM and ODM, they are welcome by us. But please offer us your authorization certification.
Q6--Is there cheap shipping cost to our country?
For small order, express will be best. And for bulk order, shipping by sea is better, but it takes much time.

Contact Rating
Dependent upon contact material
Mechanical life 50000 make-and -break cycles at full load
Contact resistance 20m Ω max.initial @2-4 VDC 100mA, for both silver and gold palted contacts
Insulation Resistance 1000M Ω min.@seal level
Operating tenmperature -30 ºC to +85 ºC
Cap installation force 10 lbs,max ,permissible

Material

Case & Bushing
Glass filled nylon6/6 or nylon 4/6(UL94v-0)
Plunger Glass filled nylon or glass filled polyester(UL 94V-0)
Switch Support Copper alloy or steel, tin palted
Switch Support Retauber Stainles steel
N.O&N.C Contacts Brass, with gold plate over nikel plate
Common contacts & all terminals copper alloy with gold plate over nickel plate
Terminal seal Epoxy
