DIP Switch for Piano (DA-02)

  • DA-02

  • Multi Control Switch

  • Power Built-in Type

  • Control Button, Limit Button

  • Double-pole on-off Switch

  • Type c Contact

  • Retro-reflective Mode

  • Bne

  • ISO9001, UL, CCC

  • BNE

  • Tube Packing

  • DA-02

  • China

  • 85365000

DIP Switch for Piano (DA-02)1. MECHANICAL

1. Operation Force: 8N Max
2. Operation Temp: -25~+70
3. Storage Temp: -40~+85
4. Stroke: 2.0mm

2. ELECTRICAL
1. Switching rating: 25mA, 24VDC
2. Non-Switching Rating: 100mA, 50VDC
3. Contact resistance: (a) 250MΩ Max. At initial 300 MΩ . After life test
4. Insulation Resistance: 100MΩ Min, AT 500VDC
5. Capacitance: 5pF max
6. Dielectric Strength: 500VAC/1 minute
7. Circuit: Single pole double throw
8. Electrical Life: 2000 operations cycles per switch 24 VDC, 25mA

3. SOLDERING AND CLEANING PROCESSES
1. Keep all switch contacts in their "OFF" position for all operations
2. WAVW SOLDERING: Recommended Solder Temperature at 500° F (260) max. 3 seconds
3. HAND SOLDERING: Use a soldering iron of 30 watts, controlled at 608° F (320)approximately 2 seconds while applying solder
4. When vapor methods are used do not subject the switch to solvents at temperature above 125° F (51)

Packaging & Shipping
1) Packaging: Carton
2) Shipping
Fedex, DHL, UPS, TNT for samples, 3-7 days.
By Air or by Sea for batch goods, 10-30 days.
3) Payment Terms
T/T, L/C, PayPal; 30% deposits; 70% balance before delivery

Why choose us?
1) We can provide you with different types of micro switches for your selection.
2) MOQ: 2500pcs,mixed order acceptable, welcome trial order.
3) We can provide free samples for your test.
4) Various operating force,height and colour for one switch for your choice.
5) Safety, on-time delivery, excellent quality with competitive price.
6) OEM and ODM professional design.
