Customized OEM Manufacturer Cable Terminal/Lug/Connector Types

  • SJ-Termial-07

  • Rectangular

  • AC/DC

  • ISO9001

  • Shengjia

  • Customized OEM Manufacturer Cable Terminal/Lug/Con

  • Forming, Stamping, Ect.

  • 0.2-25mm

  • Customer′s Requst

  • 100% Inspection

  • +/-0.02

  • Punch Machine

  • Progressive Mold

  • Plastic Bags; Preserving Box

  • Yellow Zinc Plated, Painted Ect.

  • Shengjia

  • Box

  • ISO9001

  • Dongguang Gunagdong

Customized OEM Manufacturer Cable Terminal/Lug/Connector TypesMetal Stamping Electrical Terminal Connector Cable Terminal Wire Terminal PCB


A. Raw Material

Copper ,BeCu, phosphor copper, Brass, Stainless steel, Aluminum, SGCC, SECC, steel, spring steel, Nickel-Silver... and all different kinds of metal;

B. SPEC

Roll material thickness is 0.05-10mm;sheet metal thickness is 0.3-20mm;

C. Surface treatment

Gold / Silver /Tin / Nickel / Zinc / Chromium / Copper-plating / Laser etching/Screen printing/Phosphating (can pass salt spray testing with 160 hours)/Black coating / Painting/ Power coating /Electrophoresis / Passivating /Deburring / Polishing / Brush according to ROHS standard;

D. Application

All different kinds of telecom products, Automotive, high-end digital cameras, Medical Equipment, Remote, Washing machines , vacuum cleaners, desk lamp, Furniture, Switch Power Supply, Socket, water heater, High-end toys, Calculator, Electrical, Interphone, Wireless Mouse, Wifi Router, Cordless telephone, mobile phone, Mobile DVD, Sounder. Auto Clutch, bicycle brake, scooter and so on ;

E. Quotation

Please provide the Formal drawings (normally, with DWG/STP/PDF file ),and make note with material/QTY/surface treatment and any other requirements, we will provide you the quotation sheet in 48-72 hours;

F. Prototype & Mould

We make the prototypes or moulds according to the drawings that confirmed by both of us and customers! The lead time is depends on the structure and qty of parts, Normally, lead time for prototypes is 3-15 days; lead time for mould is 10-25 days;

G. Production

We will provide samples according to the drawings to customers for approval. Then arrange the production and confirm the delivery date according to the Purchase Order; Normally , the lead time for production is 5-30 days ,the structure of parts is different , the lead time will be different .

H. Package

Plastic bags; Preserving Box; Reel/tape package; Plastic tray; Wood box; Export carton and any other customized package according to the customers' requests.


OEM and CUSTOMIZED SERVICE
1).Quality guarantee
? Chemical checking
? NDE after rough machining
? Mechanical testing after heat treatment
? Final NDE,dimension inspected
2).Quality document
? Full Q.A document as per client request
3).Packing and Shipping
? standard export package(carton/wooden case/pallet)
? accept FOB,FAS,CNF,CIF DDU DDP door to door etc or customer designated shipping agent
4).Service,
? Drawing: we can translate your original drawing, offer best suggestion on design
? Quality: we have full set quality control system to guarantee the best quality.
? Inspection: inspect in house, all our products must be checked 3 times before packing
5).Inspection
? In-house Foundry
? Third party inspection available upon requirement
6). Our goal
? To be your preferred partner
7). Our values
? Continuously strive to improve
? Enjoy our work
? Treat others the way we wish to be treated with honesty and integrity
? Disciplined people, disciplined thinking, disciplined action


1, Black metal stamping part is stamped by 0.5mm sheet iron Can also be produced according to customer's drawings and designs Various specifications available according to customer's different needs Stamping Parts for Microwave Oven Crust,
Air Conditioner, House Appliances, Car Parts , Furniture Parts, Machinery Parts, Industrial need, Metal Box & Case, etc.

2, Process

Stamping:

shearing-blanking-punching-bending-stretching-turning up edging-trimming - molding

Spraying:

alkaline degreasing-water scrubbing-acid pickling-water scrubbing-electrolytic degreasing-surface conditioning-phosphate-spraying-baking-checking-packing

Plating:

alkaline degreasing-water scrubbing-acid pickling-water scrubbing-electrolytic degreasing-neutralization-plating-water scrubbing-passivating-sealing course-baking- checking

3, Surface Treatment: lacquer,plating,sand blasting, powder coating,ect.


FAQ


Q: What's your manufacture capability?
---- We use Sodick/Charmilles to frabricate die inserts,dimension we can do is +/-0.005mm.
Q: Can you make all the dimensions are according to our design/sample?
---- We can guarantee that all the dimensions are made according to your drawing/sample.Please notice that dimension tolerence we can do is +/-0.003mm.
Q:Did the mold suit for my press machine?
---The mold is made according to your press machine's specification.Before start making die parts,we will send the design for your approval.
Q:What's your advantage compare with other supplier's on the market?
----We are stamping factory,have a team contains die design,making,maintance and stamping production.We know how important the good mold for stamping production.
----All our engineers are with more than 10 years working experience.They are more professional on precision stamping field.
----All the die parts we made are by Slow-speed wire EDM,can gurantee the dimension.Many of them make it by middle-speed wire EDM/fast-speed wire EDM.
----We are ISO/TS certificated factory,all our works are according to it.
----We have been approvaled by the thrid party,if you want,i can show you the report.
