ULTRA SMALL MINI ROCKER SWITCHES UP TO 10(4)A 250VAC
Features
1.Desktop profile,0.60 inch (15.2mm) from PCB (no keycap)
2.Choice of feel: linear,soft tactile ,click tactile
3.PCB or frame mount
4.Long life 50 million operations
5.4mm travel
6.LED,diode or jumper option
7.12V maximum AC/DC
8.Current Rating:10mA
9.Insulation Resistance:<100M Ω at 100V DC
Basic specfication parameter
1.Rating: 12VAC/DC max.10mA AC/DC max
2.Contact Resistance: ≤200m Ω
3.Insulation Resistance: ≥100m Ω DC500V
4.Withstand Voltage: AC100V 1 Minute
5.Electrical Life: 50,000,000 Cycles above (Load)
6.Operating force range: See detail spec
7.Mechanical Life: 50,000,000 Cycles(No Load)
8.Operating temperature range:-25ºC+80ºC
9.Ambient humidity used: ≤85%RH
10.Solder ability: 260ºC±5ºC 3S±0.5S
11.Withstand Soldering temperature: 260ºC±5ºC 3S±1S
12.Hand soldering: Use a soldering iron of 30 watts,controlled at 350ºC approximately 3 seconds while solder applying
X5 SERIES HEAVY DUTY SEALED ROCKER SWITCHES, Multi Ciruit, Various Actuator type, UP TO 20(8)A 125/250VAC;16A DC6~30V, SEALED TO IP67 |
|
Applications Mainly Applied On Computer Keyboards, Cash Registers, Industrial Equipment And Man-Machine Interface Basic specfication Parameter | | | Electrical Characteristics | Rating | 12VAC/DC max. 10mA AC/DC max | Contact Resistance | ≤200mΩ | Insulation Resistanc | ≥100m Ω DC500V | Withstand Voltage | AC100V 1 Minute | Electrical Life | 50,000.000 Cycles above (Load) | Mechanical/Reliability Characteristics | Operating Force Range | see detail spec | Mechanical Life | 50,000,000 Cycles (NO Load) | Operating Temperature Range | -25ºC+ 80ºC | Ambient Humidity Used | ≤85%RH | Solder Ability | 260ºC±5ºC 3S±0.5S | Withstand Soldering Temperature | 260ºC ±5ºC 3S±1S | Hand soldering | Use a soldering iron of 30 watts,controlled at 350 approximately 3 seconds while solder applying | |
Product Description
Applications include low power on/off designs, instrumentation, telecommunications, performance audio, computers/servers, networking and more.
1) Computer products
2) Consumer products
3) Communication equipments
4) Instrumentation
Features
1) Small Size
2) Full color LED illuminated available
3) Long electrical life cycles
4) SMT and vertical PCB terminal
Packaging & Shipping
1) Packaging: Carton
2) Shipping
FedEx, DHL, UPS, TNT for samples, 3-7 days.
By Air or by Sea for batch goods, 10-30 days.
3) Payment Terms: T/T, L/C, PayPal; 30% deposits; 70% balance before delivery
Why choose us?
1) We can provide you with different types of micro switches for your selection.
2) MOQ: 2500PCS, mixed order acceptable, welcome trial order.
3) We can provide free samples for your test.
4) Various operating force, height and colour for one switch for your choice.
5) Safety, on-time delivery, excellent quality with competitive price.
6) OEM and ODM professional design.
7) Our cooperative partner
Our clients include famous domestic public corporations, such as Joyoung, H&T, Topband, Newcapec, Routon, Haier, Siasun, Treyo. Also we cooperate with many famous overseas brand, such as Whirlpool, Siemens, Electrolux, Panasonic, Eaton, Emerson etc.
FAQ
Q1--What is your MOQ?
In general, Our MOQ is 2500 PCS, it will be more convenient and safety on packaging. Of course, it can be negotiable according to your situation.
Q2--What is the delivery time?
3-7 days for samples; 10-30 days for batch goods.
Q3--Can you give me samples to test and how many samples?
Yes, we provide free samples, with shipping and taxes paid by the buyer. Usually, free samples are 5 pieces.
Q4--Does your products through UL, RoHS certification and so on?
Yes, our switches are with UL, cUL, VDE, TUV, ENEC, CE, EK, CQC, Nimko, Fimko, Simko, Dimko, CB approved, meet EU, RoHS standard.
Q5--Can you accept OEM?
Yes, we can accept OEM and ODM, they are welcome by us. But please offer us your authorization certification.
Q6--Is there cheap shipping cost to our country?
For small order, express will be best. And for bulk order, shipping by sea is better, but it takes much time.
|
6A 125VAC, 3A 250VAC ( UL, CUL ) 3A 250VAC T100/55 (VDE, ENEC, KC) 3A 250VAC (CQC) Initial contact resistance : 20m ohm MAX. Insulation resistance : 100M ohm MIN. at 500VDC Dielectric strength : 1,000VAC FOR 1 MINUTE. Electrical life : 10,000 cycles. | Temperature range : 0 to + 100 degrees in Celsius Base : Nylon 66, UL rated 94V-2 min Actuator : Nylon 66, UL rated 94V-2 min Spring : Piano wire Contacts: Silver alloy Terminals: Silver plated copper alloy Patent No: M400077 (TAIWAN) Patent No: 1918990 (CHINA) |
Rating | 16A 125/250VAC(UL, CUL) 15A 125VAC(PSE) |
Electrical Life | 10,000 cycles |
Contact Resistance | 30mΩ max |
Dielectric Strength | 1,500VAC 1minute |
Insulation Resistance | 1,00MΩ min, at 500VDC |
Temperature Range | T85 |
